Network Cameras

PNM-9020V

Ngừng sản xuất

Copy a URL
Copy

7.3M H.265 Panoramic 180˚ Camera

Key Features
• Max. 7.3M (4096 x 1800) resolution
• Built-in 3.6mm fixed lens
• H.265/H.264 : Max. 30fps at all resolutions
• MJPEG : Max. 15fps at all resolutions
• H.265, H.264, MJPEG codec, WiseStream supported
• Hand over to PTZ, Tampering, Digital auto tracking
• Heatmap
• IP66, IK10

※ Product availability may vary by region.
Please contact your regional representative.

※ Hanwha Vision is formerly known as Hanwha Techwin

Datasheet
Contact Sales

Nhấp Chuột lên hình để phóng to

Ngừng sản xuất

Copy a URL
Copy

Tải hình ảnh Tổng số hình ảnh tải xuống

PNM-9020V

7.3M H.265 Panoramic 180˚ Camera

Key Features

• Max. 7.3M (4096 x 1800) resolution
• Built-in 3.6mm fixed lens
• H.265/H.264 : Max. 30fps at all resolutions
• MJPEG : Max. 15fps at all resolutions
• H.265, H.264, MJPEG codec, WiseStream supported
• Hand over to PTZ, Tampering, Digital auto tracking
• Heatmap
• IP66, IK10

※ Product availability may vary by region.
Please contact your regional representative.

※ Hanwha Vision is formerly known as Hanwha Techwin

Datasheet
Contact Sales
PNM-9020V
Datasheet
Contact Sales

Never miss a thing

Wisenet Premium 180˚ Panoramic Camera

Four cameras in one

PNM-9020V 180˚ panoramic camera provides wide view with up to 7.3 megapixel high resolution within single camera instead of installing 4 cameras. It offers a seamless single image by merging 4 images from each sensors.

Multiple view modes

The Multi sensor camera offers panoramic(16:9), half panoramic(4:3) and 3PTZ modes with a panoramic view.

Improved bandwidth efficiency with WiseStream, H.265

WiseStream, the advanced compression technology can reduce bandwidth by 50% by using dynamic technologies. And when combined with H.265, the bandwidth efficiency can be improved up to 75% compared to the current H.264 technology.

Optimized for Indoor and Outdoor

Wisenet P series multi-sensor/multi-directional cameras provide a wide area of coverage in extreme detail. They are ideal for applications such as parking lots, shopping mall entrances, lobbies, station concourses and airports.

Thông số sản phẩm

  • Video
  • Lens
  • Pan / Tilt / Rotate
  • Operational
  • Network
  • General
  • Environmental & Electrical
  • Mechanical
  • Video
    Imaging Device 1/2.8" 2MP CMOSx4
    Resolution [Panorama]
    4096x1800, 3584x1576, 3072x1352, 2560x1124, 2048x900, 1536x676, 1024x452, 512x224, 720x576
    [Halfview]
    2048x1536, 1600x1200, 1024x768, 800x600
    Max. Framerate H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
    MJPEG: Max. 15fps(60Hz/50Hz)
    Min. Illumination Color: 0.3Lux(F2.0, 1/30sec)
    B/W: 0.03Lux (F2.0, 1/30sec)
    Lens
    Focal Length (Zoom Ratio) 3.6mm Fixed
    Max. Aperture Ratio F2.0
    Angular Field of View H: 180°, V: 84°
    Min. Object Distance 1.5m(4.92ft)
    Focus Control Fixed
    Pan / Tilt / Rotate
    Pan / Tilt / Rotate Range 0°~355° / 0°~60° / -
    Operational
    Camera Title Displayed up to 45 characters
    Day & Night Auto(ICR)
    Backlight Compensation BLC
    Digital Noise Reduction SSNRⅢ
    Defog Support
    Motion Detection 8ea, 8point polygonal zones
    Privacy Masking 16ea, polygonal zones
    - Color: Grey/Green/Red/Blue/Black/White
    Gain Control Low / Middle / High
    White Balance ATW / AWC / Manual / Indoor / Outdoor
    Electronic Shutter Speed Minimum / Maximum / Anti flicker (2~1/12,000sec)
    Video Rotation Flip, Mirror
    Analytics Defocus detection, Motion detection, Appear/Disappear, Enter/Exit, Tampering, Virtual line, Audio detection
    Business Intelligence Heatmap
    Alarm I/O Input 1ea / Output 1ea
    Alarm Triggers Analytics, Network disconnect, Alarm input
    Alarm Events File upload via FTP and e-mail
    Notification via e-mail
    SD/SDHC/SDXC recording at event triggers
    Alarm output
    Network
    Ethernet RJ-45(10/100/1000BASE-T)
    Video Compression H.265/H.264: Main/Baseline/High, MJPEG
    Smart Codec Manual(5ea area)
    Bitrate Control H.264/H.265: CBR or VBR
    MJPEG: VBR
    Streaming Unicast(15 users) / Multicast
    Multiple streaming(Up to 10 profiles)
    Protocol IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
    Security HTTPS(SSL) Login Authentication
    Digest Login Authentication
    IP Address Filtering
    User access log
    802.1X Authentication(EAP-TLS, EAP-LEAP)
    Application Programming Interface ONVIF Profile S/G
    SUNAPI(HTTP API)
    General
    Web Viewer Supported OS: Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12
    Recommended Browser: Google Chrome
    Supported Browser: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only)
    Edge Storage Micro SD/SDHC/SDXC 1slot 128GB
    Memory 8GB RAM, 4GB Flash
    Environmental & Electrical
    Operating Temperature / Humidity -40°C ~ +55°C(-40°F ~ +131°F) / Less than 90% RH
    *Start up should be done at above -35°C
    Storage Temperature / Humidity -40°C ~ +60°C(-40°F ~ +140°F) / Less than 90% RH
    Certification IP66, IK10
    Input Voltage PoE+(IEEE802.3at, Class4), 12VDC
    Power Consumption PoE+: Max 25.5W
    12VDC: Max 21.0W
    Mechanical
    Color / Material Ivory / Aluminum
    Product Dimensions / Weight Ø199x143.5mm, 2025g
