PNM-C12083RVD

Copy a URL
Copy

6MP x 2CH AI Multi-directional Camera

Key Features
• Analytics events based on AI engine: Classified object(Person/Face/Vehicle/License plate)
Attributes(vehicle type: Car/Bus/Truck/Motorcycle/Bicycle)
Support BestShot
• WiseNRⅡ, Auto prefer shutter control, WiseStreamⅢ, extremeWDR (120dB)
• Maximum 3328x1872 resolution
• Maximum 15fps@6M
• Color: 0.16lux(F1.67, 1/30sec, 30IRE), 0 Lux (IR LED on)
• 3.54~6.69mm motorized varifocal, 78° tilt angle
• IR viewable length: IR 25m(82ft) based on scene
• TPM 2.0(FIPS 140-2 certified)
• IP66, IK10, NEMA4X

※ Product availability may vary by region.
       Please contact your regional representative.

? Hanwha Vision is formerly known as Hanwha Techwin

Mouse over image to zoom

Copy a URL
Copy

PNM-C12083RVD

6MP x 2CH AI Multi-directional Camera

Key Features

• Analytics events based on AI engine: Classified object(Person/Face/Vehicle/License plate)
Attributes(vehicle type: Car/Bus/Truck/Motorcycle/Bicycle)
Support BestShot
• WiseNRⅡ, Auto prefer shutter control, WiseStreamⅢ, extremeWDR (120dB)
• Maximum 3328x1872 resolution
• Maximum 15fps@6M
• Color: 0.16lux(F1.67, 1/30sec, 30IRE), 0 Lux (IR LED on)
• 3.54~6.69mm motorized varifocal, 78° tilt angle
• IR viewable length: IR 25m(82ft) based on scene
• TPM 2.0(FIPS 140-2 certified)
• IP66, IK10, NEMA4X

※ Product availability may vary by region.
       Please contact your regional representative.

? Hanwha Vision is formerly known as Hanwha Techwin

Product Specification

  • Video
  • Lens
  • Pan / Tilt / Rotate
  • Operational
  • Network
  • General
  • Environmental & Electrical
  • Mechanical
  • Certifications & Standards
  • DORI (EN62676-4 standard)
  • Video
    Imaging Device 1/2.8" CMOS x 2CH
    Resolution 3328x1872, 3072x1728, 2592x1944, 2688x1520, 1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720, 1024x768,
    800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
    Max. Framerate H.265/H.264: 6MP Max.15fps
    MJPEG: Max.15fps
    Min. Illumination Color: 0.16lux(F1.67, 1/30sec, 30IRE)
    BW: 0.016lux(F1.67, 1/30sec, 30IRE), 0lux(IR LED on)
    Video Out USB: micro USB Type B, 1280x720 for installation
    Lens
    Focal Length (Zoom Ratio) 3.54~6.69mm(1.9x) motorized varifocal
    Max. Aperture Ratio F1.67(Wide)~F2.64(Tele)
    Angular Field of View H: 96˚(Wide)~47˚(Tele)
    V: 51˚(Wide)~26˚(Tele)
    D: 113˚(Wide)~54˚(Tele)
    Min. Object Distance 1.5m(4.92ft)
    Focus Control Simple focus
    Lens Type Fixed IRIS
    Pan / Tilt / Rotate
    Pan / Tilt / Rotate Range 0~355° / 0~78° / 0~180°
    Operational
    Camera Title Displayed up to 85 characters
    Day & Night Auto(ICR)
    Backlight Compensation BLC, WDR, SSDR
    Wide Dynamic Range extremeWDR(120dB)
    Digital Noise Reduction WiseNRⅡ(Based on AI engine), SSNRⅤ
    Motion Detection 8ea, 8point Polygonal zones
    Privacy Masking 6ea, Quadrangle zones
    - Color : Gray/Black/White
    Gain Control Low / Middle / High
    White Balance ATW / AWC / Manual / Indoor / Outdoor
    LDC Support
    Electronic Shutter Speed Minimum / Maximum / Anti flicker (1/5~1/12,000sec)
    Auto prefer shutter control(Based on AI engine)
    Video Rotation Flip, Mirror, Hallway view (90°/270°) - Each channel separately
    Analytics Classified object type : Person/Face/Vehicle/License plate
    Attributes : Vehicle(Type:car/bus/truck/motorcycle/bicycle)
    Support Bestshot
    Analytics events based on AI engine
    - Object detection, Virtual line(Crossing/Direction), Virtual area(Loitering/Intrusion/Enter/Exit)
    Analytics events*
    - Defocus detection, Motion detection, Tampering, Virtual area(Appear/Disappear)

    * Support Audio detection, Sound classification via optional SPM-4210 I/O box
    Alarm I/O * Support Alarm via optional SPM-4210 I/O box
    Alarm Triggers Analytics, Network disconnect, Alarm input via optional SPM-4210 I/O box
    Alarm Events When alarm trigger occurred
    - File upload(image) : e-mail/FTP
    - Notification : e-mail
    - Recording : SD/SDHC/SDXC or NAS recording at event triggers
    - Handover(PTZ preset, Send message by HTTP/HTTPS/TCP)
    - Alarm output via optional SPM-4210 I/O box
    Audio In * Audio in via optional SPM-4210 I/O box
    Audio Out * Audio out via optional SPM-4210 I/O box
    IR Viewable Length 15m(49ft)
    25m(82ft) based on scene
    Network
    Ethernet Metal shielded RJ-45 (10/100/1000BASE-T)
    Video Compression H.265/H.264: Main/Baseline/High, MJPEG
    Smart Codec Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ(Based on AI engine)
    Bitrate Control H.264/H.265: CBR or VBR
    MJPEG: VBR
    Streaming Unicast(10 users) / Multicast
    5 profiles per channel
    Protocol IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP,
    ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast)
    Security TPM 2.0 (FIPS 140-2 level 2)
    HTTPS(SSL) Login Authentication
    Digest Login Authentication
    IP Address Filtering
    User access log
    802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2)
    Device Certificate(Hanwha Techwin Root CA, pre-installed)
    Secure by default certificate
    Secure OS/Boot/Storage, Verify firmware forgery
    Application Programming Interface ONVIF Profile S/T
    SUNAPI(HTTP API)
    Open platform
    General
    Webpage Language English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Greek, Hungarian
    Edge Storage Micro SD/SDHC/SDXC 1slot Max. 512GB
    Memory 4GB RAM, 512MB Flash
    Environmental & Electrical
    Operating Temperature / Humidity -40°C~+55°C(-40°F ~ +131°F) / Less than 95% RH(Non-condensing)
    Storage Temperature / Humidity -50°C~+60°C(-58°F~+140°F) / Less than 95% RH(Non-condensing)
    Certification IP66/IP67, NEMA4X, IK10
    Input Voltage PoE+(IEEE802.3at, Class4)
    Power Consumption PoE+: Max 21W, typical 16.5W
    Mechanical
    Color / Material White / Aluminum
    Hard-coated dome bubble
    RAL Code RAL9003
    Product Dimensions / Weight 215(W)x135(D)x93.2(H)mm(8.46"x5.31"x3.67") / 1330g
    Compatible Conduit hole / Gangbox 1/2" (M20)
    single, double, 4" octagon, 4" square
    Hanging Mount (Dome) SBP-215HMW
    Certifications & Standards
    EMC FCC 47 CFR 15 Subpart B Class A
    ICES-3(A)/NMB-3(A)
    CE/UKCA
    - EN 55032 Class A, EN 50130-4
    VCCI CISPR 32 Class A
    RCM AS/NZS CISPR 32 Class A
    KS C 9832 Class A , KS C 9835
    Safety UL 62368-1, CAN/CSA C22.2 NO. 62368-1
    IEC/EN 62471
    Environment IEC/EN 63000
    IEC/EN 60529 IP66/67, IEC/EN 62262 IK10
    NEMA 250 type 4X
    DORI (EN62676-4 standard)
    Detect (25PPM/ 8PPF) Wide: 59.9m(196.62ft) / Tele: 153.1m(502.22ft)
    Observe (63PPM/ 19PPF) Wide: 24.0m(78.65ft) / Tele: 61.2m(200.89ft)
    Recognize (125PPM/ 38PPF) Wide: 12.0m(39.32ft) / Tele: 30.6m(100.44ft)
    Identify (250PPM/ 76PPF) Wide: 6.0m(19.66ft) / Tele: 15.3m(50.22ft)
  • • The latest product information / specification can be found at hanwha-security.com
    • Design and specifications are subject to change without notice.
    • Wisenet is the proprietary brand of Hanwha Techwin, formerly known as Samsung Techwin.
