Lenses
SLA-T4615V
2MP Lens Module
Key Features
• Color: 0.06Lux (F2.5, 1/30sec, 30IRE) / BW: 0.06Lux (F2.5, 1/30sec, 30IRE)
• 4.6mm fixed focal
• Product Dimensions / Weight: 30.0x20.2x45.0mm (1.18x0.90x1.77"), 220g(0.49 lb)
• EN IEC 63000, IEC 60529 IP66, IEC 62262 IK10, NEMA 250 type 4X
• 4.6mm fixed focal
• Product Dimensions / Weight: 30.0x20.2x45.0mm (1.18x0.90x1.77"), 220g(0.49 lb)
• EN IEC 63000, IEC 60529 IP66, IEC 62262 IK10, NEMA 250 type 4X
Product availability may vary by region.
Please contact your regional representative.
Hanwha Vision is formerly known as Hanwha Techwin.
Product Specification
| Video | |
|---|---|
| Imaging Device | 1/2.8" CMOS |
| Min. Illumination | Color: 0.06Lux(F2.5, 1/30sec, 30IRE) BW: 0.06Lux(F2.5, 1/30sec, 30IRE) |
| Lens | |
| Focal Length (Zoom Ratio) | 4.6mm fixed focal |
| Max. Aperture Ratio | F2.5 |
| Angular Field of View | H: 73°, V: 39°, D: 85° |
| Mount Type | RJ12 connected with main unit |
| Focus Control | Fixed |
| Mechanical | |
| Color / Material | Black / Plastic |
| Product Dimensions / Weight | 30.0x20.2x45.0mm(1.18x0.90x1.77"), 220g(0.49 lb) Cable: 1.5m(4.92ft) |
