HCV-7030RA
QHD (4MP) Analog Vandal-Resistant IR Dome Camera
Key Features
• QHD (2560 x 1440, 30fps) resolution
• 0.27 Lux@F2.0 (Color) (HCV-7020R/7030R),0 Lux (B/W : IR LED on)
• Built-in 6.0mm fixed lens (HCV-7030R)
• Day & Night (ICR), DWDR, Motion detection
• IR Viewable Length 30m(7030R)
• Transmission distance max.500m
• Easy installation (Plug & play), IP66, IK10
• 0.27 Lux@F2.0 (Color) (HCV-7020R/7030R),0 Lux (B/W : IR LED on)
• Built-in 6.0mm fixed lens (HCV-7030R)
• Day & Night (ICR), DWDR, Motion detection
• IR Viewable Length 30m(7030R)
• Transmission distance max.500m
• Easy installation (Plug & play), IP66, IK10
※ Product availability may vary by region.
Please contact your regional representative.
※ Hanwha Vision is formerly known as Hanwha Techwin
Mouse over image to zoom
HCV-7030RA
QHD (4MP) Analog Vandal-Resistant IR Dome Camera
Key Features
• QHD (2560 x 1440, 30fps) resolution
• 0.27 Lux@F2.0 (Color) (HCV-7020R/7030R),0 Lux (B/W : IR LED on)
• Built-in 6.0mm fixed lens (HCV-7030R)
• Day & Night (ICR), DWDR, Motion detection
• IR Viewable Length 30m(7030R)
• Transmission distance max.500m
• Easy installation (Plug & play), IP66, IK10
※ Product availability may vary by region.
Please contact your regional representative.
※ Hanwha Vision is formerly known as Hanwha Techwin
Product Specification
- Video
- Lens
- Pan / Tilt / Rotate
- Operational
- Environmental & Electrical
- Mechanical
-
-
Video Imaging Device 1/3" 4MP CMOS Resolution 2560x1440 Max. Framerate 30fps@4M(N), 25fps@4M(P) Min. Illumination Color: 0.27Lux(F2.0, 1/30sec)
BW: 0Lux(IR LED on)Video Out BNC(AHD), additional CVBS for installation(2Pin connector type) Video Transmission Distance 500m(5C2V Coaxial Cable) Lens Focal Length (Zoom Ratio) 6.0mm fixed Max. Aperture Ratio F2.0 Angular Field of View H: 49.01°, V: 27.61°, D: 55.60° Min. Object Distance 0.5m(1.64ft) Pan / Tilt / Rotate Pan / Tilt / Rotate Range 0°~350° / 0°~67° / 0°~355° Operational Day & Night Auto(ICR) Backlight Compensation UserBLC, HLC, DWDR Digital Noise Reduction 2DDNR Motion Detection 4 zones Privacy Masking 2 zones Gain Control Low / Middle / High / Very High White Balance ATW / AWC / Manual / Indoor / Outdoor Electronic Shutter Speed 1/30 ~ 1/12,000sec(N), 1/25~ 1/12,000sec(P) Video Rotation H-Rev/V-Rev Analytics Motion detection IR Viewable Length 30m(98.43ft) Coaxial Protocol ACP(AHD Coax Protocol), CVBS: Pelco-C(Coaxitron) Environmental & Electrical Operating Temperature / Humidity -30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH
* Start up should be done at above -10°CCertification IP66, IK10 Input Voltage 12VDC Power Consumption Max 5W Mechanical Color / Material Ivory / Aluminum Product Dimensions / Weight Ø120.3 x 91.7mm(Ø4.74”x3.61”), 510g(1.12 lb)
-
