Network Cameras


4M H.265 IR Flateye Camera

Key Features
• Max. 4Megapixel (2592 x 1520) resolution
• 3.2~10mm (3.1x) motorized varifocal lens
• 0.2Lux@F1.6 (Color), 0Lux (B/W)
• Max. 20fps@4Megapixel (H.265 / H.264), 30fps@2Megapixel
• H.265, H.264, MJPEG codec support, Multiple streaming, Day & Night, WDR (120dB)
• Tampering, Motion detection, Defocus detection
• microSD / SDHC / SDXC memory slot (Max. 128GB)
• Hallway view, WiseStream support, LDC, PoE / 12V DC
• IR Viewable length 30m


Product availability may vary by region.
Please contact your regional representative.

Hanwha Vision is formerly known as Hanwha Techwin.


4MP QHD and 2MP Full HD Flateye IR Dome Cameras

QNE-7080RV / 7080RVW / 6080RV / 6080RVW

The new high resolution flateye dome camera will solve existing problems of conventional dome cameras.
  • IR diffused reflection such as IR separation, IR halo or IR glare
  • Solve the moisture problem since the camera imager sealed within the aluminum housing
  • Reduce the problem of the view being obscured by external contamination or scratching
  • Save the labor costs since there is no need to remove and mount a dome cover

4MP and 2MP resolutions

Wisenet offers two types of resolutions to give you the freedom to choose the camera that best fits your security needs. The higher quality resolution allows for more accurate forensic inspection of a person’s face or a license plate.

3.1x motorized varifocal lens

The 3.2~10mm varifocal lens supports True H : 104.2° (Wide) ~ 31.2° (Tele) with more flexibility in field of view.

Defocus Detection

Defocus Detection helps recognizing images that are out of focus and significantly improves efficiency. Users can also adjust the optimal focus remotely via network (4MP Varifocal product), reducing the installation time of the camera.

IR viewable length : 30m

Now you will always have clear footage up to 30m (98ft) in challenging light conditions or pitch-black darkness.

Hallway View for monitoring vertical shaped areas

In a vertical shaped environment, traditional horizontal shaped videos focus on unnecessary edges of the area causing bandwidth and storage waste. The Hallway View creates 3 : 4 and 9 : 16 ratio image which is vertically oriented and maximizes image quality in a narrow environment.

Minimize image distortion by Lens Distortion Correction

Lens distortion is typically shown in video on the straight lines near to edges of a image making the straight lines look curved outward. With Lens Distortion Correction technology imperfections in images are easily removed.

Improved bandwidth efficiency with WiseStream, H.265

WiseStream, the advanced compression technology can reduce bandwidth by 50% by using dynamic technologies. And when combined with H.265, the bandwidth efficiency can be improved up to 75% compared to the current H.264 technology.

Durable in extreme environmental conditions

Ingress protection : IP66
Impact protection : IK10

Faster installation

The newly released flateye camera used a flat window glass lens that doesn’t need a dome cover. Faster installation is also possible since there is no need to remove and mount a dome cover.

Plug-in FREE webviewer

The Wisenet Q series supports various web browsers, not only Microsoft Edge but also Chrome and Firefox without plug-in. All camera setting is controlled on plug-in free webviewer.

Product Specification

Imaging Device 1/3" 4MP CMOS
Resolution 2592 x 1520, 2560 x1440 (16 : 9),
2304 x 1296, 1920 x 1080, 1280 x 1024,
1280 x 960, 1280 x 720, 1024 x 768,
800 x 600, 800 x 448, 720 x 576,
720 x 480, 640 x 480, 640 x 360,
320 x 240
Max. Framerate H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 15fps/12fps(60Hz/50Hz)
Min. Illumination Color: 0.2Lux(F1.6, 1/30sec)
BW: 0Lux(IR LED on)
Focal Length (Zoom Ratio) 3.2~10mm(3.1x) motorized varifocal
Max. Aperture Ratio F1.6(Wide)~F2.9(Tele)
Angular Field of View H: 100°(Wide)~30.5°(Tele) / V: 55.7°(Wide)~18.3°(Tele) / H: 119.6°(Wide)~35.3°(Tele)
Focus Control Simple focus
Pan / Tilt / Rotate
Pan / Tilt / Rotate Range 0°~350° / 0°~70° / 0°~355°
Camera Title Displayed up to 20 characters
Day & Night Auto(ICR)
Backlight Compensation BLC, WDR, SSDR
Wide Dynamic Range 120dB
Digital Noise Reduction SSNR
Motion Detection 4ea, polygonal zones
Privacy Masking 6ea, rectangular zones
Gain Control Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor
LDC Support
Electronic Shutter Speed Minimum / Maximum / Anti flicker
Video Rotation Flip, Mirror, Hallway view(90°/270°)
Analytics Defocus detection, Motion detection, Tampering
Alarm I/O Input 1ea / Output 1ea
Alarm Triggers Analytics, Network disconnect, Alarm input
Alarm Events File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers
Alarm output
Audio In Line in
Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm
IR Viewable Length 30m(98.42ft)
Ethernet RJ-45(10/100BASE-T)
Video Compression H.265/H.264, MJPEG
Audio Compression G.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
Smart Codec WiseStreamⅠ
Bitrate Control H.264/H.265: CBR or VBR
Streaming Unicast(6 users) / Multicast
Multiple streaming (Up to 3 profiles)
Security HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP)
Application Programming Interface ONVIF Profile S/G
Web Viewer Supported OS: Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12
Recommended Browser: Google Chrome
Supported Browser: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only)
Edge Storage Micro SD/SDHC/SDXC 1slot 256GB (TBD)
Memory 512MB RAM , 256MB Flash
Environmental & Electrical
Operating Temperature / Humidity -30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH
Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
Certification IP66, IK10
Input Voltage PoE(IEEE802.3af, Class3), 12VDC
Power Consumption PoE: Max 8.6W
12VDC: Max 7.7W
Color / Material Ivory / Aluminum
RAL Code RAL9003
Product Dimensions / Weight Ø144.9x135.5mm(Ø5.7x5.33"), 1.3Kg(2.87lb)
