TNV-8011C
5MP Corner Mount Camera
Key Features
• Maximum 5MP resolution
• Maximum 30fps @ all resolutions (H.265/H.264/MJPEG)
• 0.1lux@F2.3(Color), 0.02lux@F2.3(B/W)
• 2.3mm fixed focal
• Anti-ligature design for corrections and behavioral health facilities
• Day & Night Auto(ICR), WDR (120dB)
• Defocus detection, Tampering, Audio detection
• Micro SD/SDHC/SDXC memory slot (128GB)
• Hallway view, WiseStream II support
• PoE, IP66, IP6K9K, IK10
• Maximum 30fps @ all resolutions (H.265/H.264/MJPEG)
• 0.1lux@F2.3(Color), 0.02lux@F2.3(B/W)
• 2.3mm fixed focal
• Anti-ligature design for corrections and behavioral health facilities
• Day & Night Auto(ICR), WDR (120dB)
• Defocus detection, Tampering, Audio detection
• Micro SD/SDHC/SDXC memory slot (128GB)
• Hallway view, WiseStream II support
• PoE, IP66, IP6K9K, IK10
※ Product availability may vary by region.
Please contact your regional representative.
※ Hanwha Vision is formerly known as Hanwha Techwin
Mouse over image to zoom
TNV-8011C
5MP Corner Mount Camera
Key Features
• Maximum 5MP resolution
• Maximum 30fps @ all resolutions (H.265/H.264/MJPEG)
• 0.1lux@F2.3(Color), 0.02lux@F2.3(B/W)
• 2.3mm fixed focal
• Anti-ligature design for corrections and behavioral health facilities
• Day & Night Auto(ICR), WDR (120dB)
• Defocus detection, Tampering, Audio detection
• Micro SD/SDHC/SDXC memory slot (128GB)
• Hallway view, WiseStream II support
• PoE, IP66, IP6K9K, IK10
※ Product availability may vary by region.
Please contact your regional representative.
※ Hanwha Vision is formerly known as Hanwha Techwin
TNV-8011C
Compact & Anti-ligature design and wide FoV
With the dimension of 170(W)x165(H)x78.8(D)mm(6.69×6.49×3.10″) and the weight of 830g(1.83lb), TNV-8011C offers a wide FoV (H: 131° / V: 93.4° / D: 174°), making it suitable for SMB and limited space monitoring. And its anti-ligature design makes it also applicable for corrections and behavioral health facilities.
Product Specification
- Video
- Lens
- Operational
- Network
- General
- Environmental & Electrical
- Mechanical
- DORI (EN62676-4 standard)
-
-
Video Imaging Device 1/2.8" CMOS Resolution 2592x1944, 1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360 Max. Framerate H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 15fps/12fps (60Hz/50Hz)Min. Illumination Color: 0.1 lux (F2.3, 1/30sec)
B/W: 0.02 lux (F2.3, 1/30sec)Video Out CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation
USB: Micro USB Type B, 1280x720 for installationLens Focal Length (Zoom Ratio) 2.3mm fixed focal Max. Aperture Ratio F2.3 Angular Field of View H: 131° / V: 93.4° / D: 174° Focus Control Fixed Operational Camera Title Displayed up to 85 characters Day & Night Auto(ICR) Backlight Compensation BLC, WDR, SSDR Wide Dynamic Range 120dB Digital Noise Reduction SSNR Digital Image Stabilization Support Defog Support Motion Detection 4ea, polygonal zones Privacy Masking 6ea, rectangular zones Gain Control Low / Middle / High White Balance ATW / AWC / Manual / Indoor / Outdoor(include Mercury & Sodium) LDC Support Electronic Shutter Speed Minimum / Maximum / Anti flicker (2~1/12,000sec) Video Rotation Flip, Mirror, Hallway view(90°/270°) Analytics Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line, Audio detection Alarm I/O Input 1ea / Output 1ea Alarm Triggers Analytics, Network disconnect, Alarm input Alarm Events File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers
Alarm outputAudio In Selectable(mic in/line in)
Supply voltage: 2.5VDC(4mA), Input impedance: 2K OhmAudio Out Line out, Max.output level: 1Vrms Network Ethernet RJ-45(10/100BASE-T) Video Compression H.265/H.264: Main/Baseline/High, MJPEG Audio Compression G.711 u-law /G.726 selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40KbpsSmart Codec Manual(5ea area), WiseStreamⅡ Bitrate Control H.264/H.265: CBR or VBR
MJPEG: VBRStreaming Unicast (6 users) / Multicast
Multiple streaming (Up to 3 profiles)Protocol IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, sRTP Security HTTPS(SSL) login authentication
Digest login authentication
IP address filtering
User access log
802.1X authentication(EAP-TLS, EAP-LEAP)
Device certificate(Hanwha Techwin Root CA)Application Programming Interface SUNAPI(HTTP API)
Wisenet open platformGeneral Webpage Language English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek Edge Storage Micro SD/SDHC/SDXC 1slot 128GB Memory 512MB RAM, 256MB Flash Environmental & Electrical Operating Temperature / Humidity -10℃~+55℃(+14℉~+131℉) / Less than 95% RH Storage Temperature / Humidity -50℃~+60℃(-58℉~+140℉) / Less than 95% RH Certification IP66, IP6K9K, IK10 Input Voltage PoE(IEEE802.3af, Class2) Power Consumption PoE: Max 6.49W, typical 4.6W, Mechanical Color / Material White / Aluminium RAL Code RAL9003 Product Dimensions / Weight 170(W)x165(H)x78.8(D)mm(6.69x6.49x3.10") / 830g(1.83lb) Skin Cover SBC-170C, SBC-170CB, SBC-170CW DORI (EN62676-4 standard) Detect (25PPM/ 8PPF) 23.6m(77.51ft) Observe (63PPM/ 19PPF) 9.4m(31.00ft) Recognize (125PPM/ 38PPF) 4.7m(15.50ft) Identify (250PPM/ 76PPF) 2.4m(7.75ft)
-
