PTZ

QNP-6230

2M H.265 23x PTZ Camera

Key Features

• Max. 2MP (1920 x 1080) resolution
• 4.44 ~ 102.2mm (Optical 23x) lens
• H.265, H.264, MJPEG codec support
• Multiple streaming, WiseStreamII support
• Day & Night (ICR), WDR (120dB)
• DIS with Built-in Gyro sensor
• Tamepring, Motion detection
• Memory slot (Max. 256GB)
• IP66, IK10 (QNP-6230 + SHP-3701H only)

Contact Sales Datasheet

["camera","network","ptz"]

Product availability may vary by region.
Please contact your regional representative.

Hanwha Vision is formerly known as Hanwha Techwin.

Tổng quan

Compact cameras
with essential qualities

Affordable product line offers professional qualities ideal
for securing small to medium sized applications

Wisenet-Q-Series-Hero Wisenet-Q-Series-Hero

Wisenet-Q-Series-Camera

  • 2Megapixel and 4Megapixel resolution
  • Framerate Max. 20fps@4M, 30fps@2M
  • Hallway view, Lens Distortion Correction
  • True WDR (120dB)
  • IP66/IK10 for Outdoor cameras
  • H.265, H.264, MJPEG
  • Motion and Defocus detection, Tampering
  • WiseStream
  • Edge storage
  • Compact design

Improved bandwidth efficiency with WiseStream, H.265

Improved bandwidth efficiency with WiseStream, H.265

WiseStream, the advanced compression technology can reduce bandwidth by 50% by using dynamic technologies. And when combined with H.265, the bandwidth efficiency can be improved up to 75% compared to the current H.264 technology.

Defocus detection

Defocus detection

Defocus detection helps recognizing images that are out of focus and significantly improves efficiency. Users can also adjust the optimal focus remotely via network (4MP Varifocal product), reducing the installation time of the camera.

Various lens options

Fixed Lens

Varifocal Lens

Even with backlight, Wisenet’s cutting-edge WDR technology addresses a limitation found in conventional WDR cameras while producing clear and vivid images. WDR improves the accuracy of an image by resolving the difference in brightness.

The 2.8 ~ 12mm varifocal lens, created by Hanwha Techwin’s own advanced technology, supports True H : 109.7° (Wide) ~ 26.0° (Tele) with more flexibility in field of view.
Demo Video
Demo Video

Hallway View for monitoring vertical shaped areas

Hallway View for monitoring vertical shaped areas

In a vertical shaped environment, traditional horizontal shaped videos focus on unnecessary edges of the area causing bandwidth and storage waste. The Hallway view creates 3 : 4 and 9 : 16 ratio image which is vertically oriented and maximizes image quality in a narrow environment.

Minimize image distortion by Lens Distortion Correction

Minimize image distortion by Lens Distortion Correction

Lens Distortion is typically shown in video on the straight lines near to edges of a image making the straight lines look curved outward. With Lens Distortion Correction technology imperfections in images are easily removed.

Perfect for small to medium sized applications

Perfect for small to medium sized applications

By using the Wisenet Q series cameras along with NVRs, create a perfect solution for small to medium sized applications and save installation cost and time.

Thông số sản phẩm

Video
Imaging DeviceSize1/2.8"
TypeCMOS
Resolution1280x720, 1280x1024, 720x480, 1280x960, 800x448, 1920x1080, 720x576, 640x360, 1024x768, 800x600, 640x480, 320x240
Max. FramerateH.265/H.26460fps/50fps(60Hz/50Hz)
MJPEG30fps
Min. Illumination (Lux)Color(1/30sec, 30IRE)0.5
BW(1/30sec, 30IRE)0.005
Video OutCVBS: 1.0 Vp-p / 75Ω composite for installation
Lens
Focal Length (mm)4.44~102.2
Zoom RatioOptical23x
Digital800x
Max Aperture Ratio (F number)Wide1.6
Tele3.6
Angular Field of ViewHorizontal61.8°~3.08°
Vertical36.2°~1.73°
Min. Object Distance2m(6.56ft)
Focus ControlOneshot AF, Auto, Manual, Focus save
Lens TypeDC auto iris
Pan / Tilt / Rotate
Pan / Tilt / Rotate RangePan360° Endless
Tilt90°~-15°
Pan SpeedPresetMax. 500°/sec
Manual0.024°/sec~250°/sec
Tilt SpeedPresetMax. 500°/sec
Manual0.024°/sec~250°/sec
SequencePreset(300ea), Swing, Tour, Group(6ea), Schedule, Trace, Auto Run
Preset Accuracy±0.2°
Operational
Day & NightAuto(ICR)
Backlight CompensationBLC, SSDR, WDR, HLC
Wide Dynamic Range (dB)120
Digital Noise ReductionWiseNR, SSNRⅤ
Digital Image StabilizationSupport(built-in gyro sensor)
DefogSupport
Motion DetectionQuantity8ea
Shape8point Polygonal zones
Privacy MaskingQuantity24ea
ShapePolygonal zones
Color / OptionWhite, Mosaic, Green, Red, Blue, Gray, Black
Gain ControlHigh, Low, Middle
White BalanceAWC, Manual, Indoor, ATW, Outdoor
Electronic ShutterModeMaximum, Minimum, Anti flicker
Speed Range2~1/12,000sec
Video RotationFlip&Mirror
Serial InterfaceRS-485(Samsung-T, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell)
Alarm InterfaceIn/OutInput 4ea / Output 2ea
OthersSupport alarm I/O via optional I/O box
Alarm TriggersNetwork disconnect, Analytics, Alarm input, Time schedule
Alarm Events When Alarm Trigger OccurredAlarm output, Audio clip playback, Handover: PTZ preset, send message by HTTP/HTTPS/TCP, File upload(image): e-mail/FTP, Recording: SD/SDHC/SDXC or NAS recording at event triggers, Notification: e-mail
Audio InSupport via optional I/O box
Audio OutSupport via optional I/O box
Analytics
Analytics EventsNormalTampering, Motion detection
Network
EthernetRJ-45(10/100BASE-T)
Video CompressionH.265/H.264: Main/Baseline/High, MJPEG
Smart CodecManual, WiseStreamⅡ
Bitrate ControlH.265/H.264: CBR or VBR, MJPEG: VBR
StreamingUnicastUp to 10 users
MulticastSupport
Multiple StreamingUp to 10 profiles
ProtocolDHCP, RTCP, UPnP, ICMP, UDP/IP, Bonjour, SRTP(TCP, UDP Unicast), DNS, SNMPv1/v2c/v3(MIB-2), RTP(TCP), SSL/TLS, QoS, SMTP, DDNS, IGMP, HTTP, IPv6, LLDP, RTSP, RTP(UDP), IPv4, HTTPS, FTP, NTP, TCP/IP, ARP
Application Programming InterfaceONVIFG, T, S
OthersHanwha Vision Open Platform, SUNAPI(HTTP API)
Direct Cloud ConnectionOptional (needs gateway)
Security
OS / Firmware ProtectEncrypted firmware
User authenticationDigest authentication, Prevent brute-force attack
Network authenticationIEEE 802.1X(EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2)
Secure CommunicationWSS(WebSocket Secure), HTTPS, SRTP
Access ControlIP-based access control
Data ProtectEncrypt compress for live recording file export, Encryption credentials
AuditAccess / System / Event Log management
Device IDDevice certificate(Hanwha Vision Root CA)
General
MemoryRAM1GB
Flash256MB
Edge StorageMicro SD/SDHC/SDXCMax. 256GB x 1slot
Environmental & Electrical
Operating ConditionTemperature-35°C~+55°C(-31°F~+131°F)
Humidity0~90% RH(non-condensing)
OthersStart up should be done at above -30°C
Storage ConditionTemperature-50°C~+60°C(-58°F~+140°F)
Humidity0~95% RH(non-condensing)
EPA(Effective Projected Area)0.035㎡
Input VoltagePoE+(IEEE802.3at, Class4)
Power Consumption24VACMax 20W
Mechanical
ColorIvory
MaterialAluminum
RAL CodeRAL9003
Product Dimensionsø158x293.3mm(6.22x11.55")
Product Weight3100g(6.83lb)
Certifications & Standards
EMCCE/UKCA - EN55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3, VCCI CISPR 32 Class A, FCC 47 CFR 15 Subpart B Class A, RCM AS-NZS CISPR 32 Class A, IC Regulation ICES-003 Issue 7 Class A
SafetyIEC 62471, UL 62368-1, CAN/CSA C22.2 NO. 62368-1
EnvironmentIEC/EN 63000, IEC 62262 IK10, IEC 60529 IP66
Datasheet
