Analog Cameras


1080p Analog HD 32x PTZ Dome Camera

Key Features
• Full HD (1920 x 1080, 30fps) resolution
• 0.2Lux@F1.6, B/W : 0.01Lux@F1.6
• Powerful 32x zoom (4.44 ~ 142.6mm), Digital 16x
• Day & Night (ICR), Defog, WDR (120dB), SSNRIII
• Preset 700°/sec, Azimuth
• IP66 / IK10 (HCP-6320H)
• RS-485, 24V AC


Product availability may vary by region.
Please contact your regional representative.

Hanwha Vision is formerly known as Hanwha Techwin.

Thông số sản phẩm

Imaging Device 1/2.8" 2MP CMOS
Resolution 1920x1080
Max. Framerate 30fps
Min. Illumination Color:0.2Lux(F1.6, 1/30sec)
BW: 0.01Lux(F1.6, 1/30sec)
Video Out BNC(AHD / CVBS)
Focal Length (Zoom Ratio) 4.44~142.6mm(32x) motorized varifocal
Max. Aperture Ratio F1.6(Wide)~F4.4(Tele)
Angular Field of View H: 62.8°(Wide)~2.23°(Tele) / V: 36.8°(Wide)~1.26°(Tele)
Min. Object Distance Wide: 1.4m(4.59ft), Tele: 1.9m(6.23ft)
Focus Control Auto, Manual, One push
Lens Type DC auto iris
Pan / Tilt / Rotate
Pan Range 360° Endless
Pan Speed Preset: 700°/sec, Manual: 0.024°/sec~200°/sec
Tilt Range 210°(-15°~195°)
Tilt Speed Preset: 700°/sec, Manual: 0.024°/sec~200°/sec
Sequence Preset(255ea)
Preset Accuracy ±0.2°
Camera Title Displayed up to 85 characters
Day & Night Auto(ICR)
Backlight Compensation BLC, HLC, WDR, SSDR
Wide Dynamic Range 120dB
Digital Noise Reduction SSNRⅢ
Digital Image Stabilization Support
Defog Support
Motion Detection 4ea, rectangular zones
Privacy Masking 32ea, rectangular zones
Gain Control Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor / Mercury / Sodium
Electronic Shutter Speed 2~1/12,000sec
Video Rotation Flip, Mirror
Analytics Tempering, Virtual line, Enter/Exit, (Dis)Appear, Motion detection
Serial Interface RS-485(Samsung-T/E, Pelco-P/D, Sungjin, Panasonic, Honeywell, AD, Vicon, Bosch, GE)
Alarm I/O Input 4ea / Output 2ea
Alarm Triggers Analytics
Alarm Events Alarm output
Environmental & Electrical
Operating Temperature / Humidity -50°C ~ +55°C (-58°F ~ +131°F) / Less than ~ 90% RH
Storage Temperature / Humidity -50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH
Certification IP66, IK10, Safety(UL), EMC(FCC, CE)
Input Voltage 24VAC
Power Consumption Max 24W(Heater off), 65W(Heater on)
Color / Material Ivory / Plastic + Aluminum
