LNV-6022R

Copy a URL
Copy

2MP IR Vandal Dome Camera

Key Features
• Maximum 2MP resolution
• Color: 0.03Lux(F2.0, 1/30sec) BW : 0Lux (IR LED on)
• 4.0mm fixed focal
• Maximum 30fps@2MP all resolutions (H.264)
• H.264, MJPEG codec supported, Multiple streaming
• Day & Night (ICR), WDR (120dB)
• Tampering, Motion detection
• Micro SD/SDHC memory slot (32GB), PoE
• Hallway view (90°/270°), WiseStreamII support
• IR viewable length 30m(98.43ft)
• IP66, IK10 support

※ Product availability may vary by region.
Please contact your regional representative.

※ Hanwha Vision is formerly known as Hanwha Techwin

Datasheet
Contact Sales

Для увеличения изображения наведите курсор мыши

Copy a URL
Copy

Загрузить изображение Загрузить все изображения

LNV-6022R

2MP IR Vandal Dome Camera

Key Features

• Maximum 2MP resolution
• Color: 0.03Lux(F2.0, 1/30sec) BW : 0Lux (IR LED on)
• 4.0mm fixed focal
• Maximum 30fps@2MP all resolutions (H.264)
• H.264, MJPEG codec supported, Multiple streaming
• Day & Night (ICR), WDR (120dB)
• Tampering, Motion detection
• Micro SD/SDHC memory slot (32GB), PoE
• Hallway view (90°/270°), WiseStreamII support
• IR viewable length 30m(98.43ft)
• IP66, IK10 support

※ Product availability may vary by region.
Please contact your regional representative.

※ Hanwha Vision is formerly known as Hanwha Techwin

Datasheet
Contact Sales
LNV-6022R
Datasheet
Contact Sales

Технические характеристики

  • Video
  • Lens
  • Pan / Tilt / Rotate
  • Operational
  • Network
  • Security
  • General
  • Environmental & Electrical
  • Mechanical
  • DORI (EN62676-4 standard)
  • Video
    Imaging Device 1/2.8" CMOS
    Resolution 1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360
    Max. Framerate H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
    MJPEG: Max. 10fps(@2MP Max. 2fps)
    Min. Illumination Color: 0.03Lux(F2.0, 1/30sec)
    BW : 0Lux (IR LED on)
    Lens
    Focal Length (Zoom Ratio) 4.0mm fixed focal
    Max. Aperture Ratio F2.0
    Angular Field of View H: 85° / V: 46° / D: 99°
    Min. Object Distance 0.5m(1.64ft)
    Focus Control Fixed
    Pan / Tilt / Rotate
    Pan / Tilt / Rotate Range 0°~350° / 0°~67° / 0°~355°
    Operational
    Camera Title Displayed up to 15 characters
    Day & Night Auto(ICR)
    Backlight Compensation BLC, WDR, SSDR
    Wide Dynamic Range 120dB
    Digital Noise Reduction SSNR
    Motion Detection 4ea, rectangler zones
    Privacy Masking 6ea, rectangular zones
    Gain Control Low / Middle / High
    White Balance ATW / AWC / Manual / Indoor / Outdoor
    LDC Support
    Electronic Shutter Speed Minimum / Maximum / Anti flicker (2~1/12,000sec)
    Video Rotation Flip, Mirror, Hallway view(90°/270°)
    Analytics Motion detection, Tampering
    Alarm Triggers Analytics
    Alarm Events When alarm trigger occurred
    - File upload(image) : e-mail/FTP
    - Notification : e-mail
    - Recording : SD/SDHC/SDXC or NAS recording at event triggers
    Light Type IR LED (850nm)
    Light Viewable Length 30m(98.43ft)
    Network
    Ethernet RJ-45(10/100BASE-T)
    Video Compression H.264: Main/Baseline/High, MJPEG
    Smart Codec WiseStreamⅡ
    Bitrate Control H.264: CBR or VBR
    MJPEG: VBR
    Streaming Unicast(6 users) / Multicast
    Multiple streaming (Up to 3 profiles)
    Protocol IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour
    Application Programming Interface ONVIF Profile S/G/T
    SUNAPI(HTTP API)
    Security
    OS / Firmware Protect Firmware encryption
    User authentication Digest Authentication, Prevent brute-force attack
    Network authentication 802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2)
    Secure Communication HTTPS, SRTP, WSS(Websocket secure)
    Access Control Access control based on IP address
    Data Protect Authentication information encryption, ZIP compression encryption
    Audit User Access/System/Event log management
    Device ID Device Certificate(Hanwha Private Root CA)
    Secure Storage SDcard partition encrypt
    General
    Webpage Language English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch
    Edge Storage Micro SD/SDHC 1slot 32GB
    Memory 512MB RAM, 256MB Flash
    Environmental & Electrical
    Operating Temperature / Humidity -30°C~+55°C(-22°F ~ +131°F) / 0~90% RH
    * Start up should be done at above -20°C(-4°F)
    Storage Temperature / Humidity -30°C ~ +55°C(-22°F ~ +131°F) / Less than 90% RH
    Certification IP66, IK10
    Input Voltage PoE(IEEE802.3af, Class3)
    Power Consumption Max 6.4W, Typical 5.0W
    Mechanical
    Color / Material White / Plastic, Aluminum
    RAL Code RAL9003
    Product Dimensions / Weight ø120.3x91.7mm(ø4.74x3.61"), 410g
    Hanging Mount (Dome) SBP-122HMW
    Backbox SBV-120GW
    DORI (EN62676-4 standard)
    Detect (25PPM/ 8PPF) 42.4m(139.17ft)
    Observe (63PPM/ 19PPF) 17.0m(55.67ft)
    Recognize (125PPM/ 38PPF) 8.5m(27.83ft)
    Identify (250PPM/ 76PPF) 4.2m(13.92ft)
