LED

SMT-2710

27" FHD monitor

Key Features

• 27 inch FHD Monitor, support up to 1920×1080 @60Hz
• Brightness 250 cd/m² (Typical), Contrast 3000:1 (Minimum) 4000:1 (Typical)
• Viewing Angle (H/V) : 178°/178°, Response Time : 6.5ms (Typical)
• Video Input : HDMI, DP, VGA
• Panel Life : 30,000 hours
• Designed and tested on 24/7 operation

お問い合わせ データシート

["peripherals","monitor","led"]

Product availability may vary by region.
Please contact your regional representative.

Hanwha Vision is formerly known as Hanwha Techwin.

製品の仕様

Display
TypeLED Monitor
Screen Size27inch
Max. Resolution1920x1080
Brightness250 cd/m²
Contrast Ratio4000:1
Aspect Ratio16:9
Viewing Angle (H/V)178°/178°
Display Color16.7M
Response Time6.5ms
Panel Life30,000 hours
Interface
VideoConnectorsVGA(1), HDMI(1), DP(1)
VGAConnectorVGA
Available Format1920x1080@60Hz
HDMIConnectorHDMI
Available Format1920x1080@60Hz
DPConnectorDP
Available Format1920x1080@60Hz
AudioConnectorAudio in(1)/out(1)
Output SignalSpeakers : 4Ω 2.5W x 2
On Screen Display
FunctionsVESA™ DPMS Compatible
LanguageEnglish, French, German, Italian, Simplified Chinese, Traditional Chinese, Korean, Japanese, Espanola, Portuguese, Russian, Arabic
General
ElectricalInput VoltageAC 100 ~ 240V(50/60Hz)
Power Consumption45W
EnvironmentalOperating Temperature0 ~ +40°C (+32°F ~ +104°F)
Operating Humidity10% ~ 80% (non-condensing)
MechanicalDimensions with Stand (WxHxD)614.7x452.5x224.1mm(24.2x17.8x8.8")
Dimensions without Stand (WxHxD)614.7x336.4x50.8mm(24.2x13.2x2")
Weight4.54Kg(10lb, with stand), 4.13Kg(9.1lb, without stand)
Packing Dimension (WxHxD)675*115*511mm(26.6x4.5x20.1")
Packing Weight5.53Kg(12.2lb)
Cabinet ColorBlack
VESA Mounts Interface100x100mm
