映像 |
---|
映像素子 | Size | 1/1.8" |
Type | CMOS |
解像度 | 3840x2160, 3072x1728, 2688x1520, 2592x1944, 2560x1440, 2048x1536, 1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360 |
最大フレームレート | H.265/H.264 | 30fps/25fps(60Hz/50Hz) |
MJPEG | 30fps |
最低照度 | Color(1/30sec, 30IRE) | 0.075 |
BW(1/30sec, 30IRE) | 0.0075 |
映像出力 | CVBS: 1.0 Vp-p / 75Ω composite for installation, USB: Micro USB Type B |
レンズ |
---|
Focal Length (mm) | 6.91~214.7 |
Zoom Ratio | Optical | 31x |
最大口径比 | Wide | 1.36 |
Tele | 4.6 |
画角 | Horizontal | 60.92°~2.2° |
Vertical | 35.26°~1.24° |
Diagonal | 69.18°~2.52° |
最低被写体距離 | 3m(9.84ft) |
フォーカス制御 | Simple focus |
レンズタイプ | P iris(IR corrected) |
カメラ機能 |
---|
デイナイト | Auto(ICR) |
逆光補正 | BLC, WDR, SSDR |
Wide Dynamic Range (dB) | 120 |
ノイズ軽減 | WiseNRⅡ(Based on AI engine), SSNRⅤ |
手振れ補正 | Support(built-in gyro sensor) |
モーション検知 | Quantity | 8ea |
Shape | 8point Polygonal zones |
プライバシーマスク | Quantity | 3ea |
Shape | Rectangular zones |
Color / Option | Gray, Black, White |
ゲイン制御 | Low, Middle, High |
ホワイトバランス | ATW, AWC, Manual, Indoor, Outdoor |
LDC | Support |
電子シャッター | Mode | Minimum, Maximum, Anti flicker, Prefer shutter control(Based on AI engine) |
Speed Range | 1/5~1/12,000sec |
映像回転 | Flip, Mirror, Hallway view(90°/270°) |
Alarm Interface | In/Out | 2 configurable I/O ports |
Others | 12VDC output |
アラームトリガー | Analytics, Network disconnect, Alarm input, App event, Time schedule, MQTT subscription |
アラームイベント | File upload(image): e-mail/FTP, Notification: e-mail, Recording: SD/SDHC/SDXC or NAS recording at event triggers, Alarm output, Handover: PTZ preset, send message by HTTP/HTTPS/TCP, Audio clip playback, MQTT: publication |
音声入力 | Selectable(mic in/line in) |
音声出力 | Line out |
Light Type | IR LED |
Light Viewable Length | IR | WiseIR 70m(229.66ft) |
IR Wavelength | 850nm |
Analytics |
---|
Classified Object Type | Person, Face, Vehicle, License plate |
Attributes | Person | Upper/Lower clothes color, Gender, Bag |
Vehicle | Type(car, bus, truck, motorcycle, bicycle), Color |
Face | Age, Gender, Face mask, Glasses |
Thumbnail | BestShot |
Analytics Events | Based on AI Engine | Object detection, Virtual line(Crossing/Direction), Virtual area(Loitering/Intrusion/Enter/Exit), Face mask detection, Social distancing detection, Slip & fall detection |
Normal | Defocus detection, Motion detection, Tampering, Audio detection, Sound classification, Shock detection, Virtual area(Appear/Disappear), WiseDetector for adding custom objects |
Business Intelligence | Based on AI Engine | People counting, Queue management, Heatmap, Vehicle counting, Crowd counting |
ネットワーク |
---|
イーサネット | Metal shielded RJ-45(10/100/1000BASE-T) |
映像圧縮 | H.265/H.264: Main/High, MJPEG |
音声圧縮 | G.711 u-law /G.726 selectable, G.726(ADPCM) 8kHz, G.711 8kHz, G.726: 16kbps, 24kbps, 32kbps, 40kbps, AAC-LC: 48kbps at 16kHz |
スマートコーデック | Manual, WiseStreamⅢ |
ビットレート制御 | H.265/H.264: CBR or VBR, MJPEG: VBR |
ストリーミング性能 | Unicast | Up to 6 users |
Multicast | Support |
Multiple Streaming | Up to 6 profiles |
プロトコル | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP(TCP, UDP Unicast), MQTT |
応用インターフェイス | ONVIF | S, G, T, M |
Others | SUNAPI(HTTP API), Hanwha Vision Open Platform |
Direct Cloud Connection | Support |
Security |
---|
OS / Firmware Protect | Encrypted firmware, Secure boot, Signed firmware |
User authentication | Digest authentication, Prevent brute-force attack |
Network authentication | IEEE 802.1X(EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2) |
Secure Communication | HTTPS, WSS(WebSocket Secure), SRTP |
Access Control | IP-based access control |
Data Protect | Encryption credentials, Encrypt compress for live recording file export |
Audit | Access / System / Event Log management |
Device ID | Device certificate(Hanwha Vision Root CA) |
Secure Storage | TPM(Trusted platform module), SDcard partition encrypt(AES-256) |
Security Certificate | TPM 2.0 with FIPS 140-2 level2 |
一般 |
---|
メモリー | RAM | 4GB |
Flash | 1GB |
SDカード | Micro SD/SDHC/SDXC | Max. 256GB x 2slot(Total 512GB) |
動作環境/電源 |
---|
動作温度/湿度 | Temperature | -40°C~+55°C(-40°F~+131°F) |
Humidity | 0~100% RH(condensing) |
Others | Start up should be done at above -30°C, Humidity control with AIR vent |
保管温度/湿度 | Temperature | -50°C~+60°C(-58°F~+140°F) |
Humidity | 0~90% RH(non-condensing) |
電源 | PoE+(IEEE802.3at, Class4), 12VDC |
消費電力 | PoE | Max 25.5W, typical 14.0W |
12VDC | Max 24.0W, typical 12.7.W |
物理的仕様 |
---|
カラー | White |
材質 | Aluminum |
RAL コード | RAL9003 |
寸法 | ø136.2x358.7mm(ø5.36x14.12")(Without sunshield) |
重量 | 3,200g(7.05lb) |
互換 Conduit Hole | 19.1mm(3/4")(M25) |
互換 Gang Box | Single, Double, 4" Octagon, Square |
Certifications & Standards |
---|
EMC | FCC 47 CFR 15 Subpart B Class A, ICES-3(A)/NMB-3(A), CE/UKCA - EN55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3, VCCI CISPR 32 Class A, RCM AS-NZS CISPR 32 Class A |
Safety | UL 62368-1, CAN/CSA C22.2 NO. 62368-1, IEC 62471 |
Environment | IEC/EN 63000, IEC 60529 IP66, IEC 60529 IP67, IEC 62262 IK10 |
DORI (EN62676-4 standard) |
---|
Detect (25PPM/ 8PPF) | Wide | 130.6m(428.4ft) |
Tele | 4,000m(13,122ft) |
Observe (63PPM/ 19PPF) | Wide | 52.2m(171.4ft) |
Tele | 1600m(5,249ft) |
Recognize (125PPM/ 38PPF) | Wide | 26.1m(85.7ft) |
Tele | 800m(2,625ft) |
Identify (250PPM/ 76PPF) | Wide | 13.1m(42.8ft) |
Tele | 400m(1,312ft) |
