Pole
SBP-150PMW
Pole Mount
Key Features
• Color : White
• Material : Aluminum
• Product dimensions / weight : 310x260x49mm(12.21x10.24x1.93") / 3,200g (7.06lb)
• Max. load : 40kg
Product availability may vary by region.
Please contact your regional representative.
Hanwha Vision is formerly known as Hanwha Techwin.
製品の仕様
| Mechanical | ||
|---|---|---|
| Color | White | |
| Material | Aluminum | |
| RAL code | RAL9003 | |
| Product dimensions / weight | 310x260x49mm(12.21x10.24x1.93") / 3,200g(7.06lb) | |
| Tile thickness | ※ Pole thickness ø80~200mm(ø3.15~7.88"): Using vice grip ø200mm~(ø7.88"~): Using steel strap | |
| Mount Screw size | TR30, M12 | |
| Max. load | 40kg | |
| Conduit hole | 19.1mm(3/4")(M25) | |
| Supported products | SBP-150NBW, TNO-A26081 ※ For further compatible models, please visit our website or use Toolbox | |
