10-inch AI PVM (Black)

Key Features
• 2MP AI Camera, f1.6
• SUNAPI/Onvif Profile S/G/T/M
• AI Object Classification and Analytics
• Motion and event activated LED and audio alarm
• Face Detection box
• Image Slide Show (No additional storage is required)
• Customizable text overlay with default "Recording in progress“ message
• On-screen custom logo image
• Monitor management via WebUI (Power On/Off/Scheduling, Banner etc.)
• Dual power PoE+ (802.3at) and DC24V (adapter* is not included)
* DC 24V Power Adapter (SPU-60240)

• UL Listed
• NDAA Compliant


Product availability may vary by region.
Please contact your regional representative.

Hanwha Vision is formerly known as Hanwha Techwin.

Product Specification

Type LED Monitor
Screen Size 10.1"
Max. Resolution 1024 x 600 60Hz
Brightness 500cd/m²
Contrast Ratio 500:1
Aspect Ratio 16:9
Viewing Angle (H/V) 140° / 120°
Display Color 16.7M Colors
Response Time 20ms
Panel Life 50,000 hours
Connectors Camera(Internal)
Output Signal Speakers : 8Ω 1Wx 2
Alarm I/O Input 1ea / Output 1ea
Ethernet 1 RJ-45 10/100BASE-T,
Edge Storage Micro SD/SDHC/SDXC 1slot 256GB
On Screen Display
Functions VESA™ DPM Compatible
Language English, Spanish, French
Input Voltage DC24V, PoE+ 802.3at
Power Consumption 14W
Operating Temperature 0 ~ +40°C (+32°F ~ +104°F)
Operating Humidity 10% ~ 80% (non-condensing)
Dimensions without Stand (WxHxD) 245.5mm(W) x 178.2mm(H) x 35.5mm(D)
Weight 900g
Cabinet Color Black
VESA Mounts Interface VESA 75 x 75mm
Imaging Device 1/2.8" 2MP CMOS
Max. Framerate H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 15fps/12fps(60Hz/50Hz)
Min. Illumination Color: 0.03Lux (F1.6, 1/30sec)
Focal Length (Zoom Ratio) 3.06mm fixed focal
Max. Aperture Ratio F1.6
Angular Field of View H: 107.7° / V: 59.0° / D: 126.7°
Backlight Compensation BLC, WDR, SSDR
Wide Dynamic Range 120dB
Digital Noise Reduction SSNRⅤ, WiseNRⅡ(Based on AI engine)
Motion Detection 8ea, 8point Polygonal zones
Privacy Masking 32ea, 4point Quadrangle zones
Gain Control Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor
LDC Support
Electronic Shutter Speed Minimum / Maximum / Anti flicker (1/5~1/12,000sec)
Digital PTZ Support
Video Rotation Flip, Mirror, Hallway view(90˚/270˚)
Analytics Classified object type: Person/Face
Attributes: Not support
Support DetectionShot
Analytics events based on AI engine
- Motion detection, Object detection, Virtual line(Crossing/Direction), Virtual area(Loitering/Intrusion/Enter/Exit)
Analytics events
- Defocus detection, Tampering, Virtual area(Appear/Disappear)
Business Intelligence People counting, Queue management, Heatmap based on AI engine
Alarm Triggers Analytics, Network disconnect, Alarm input
Alarm Events When alarm trigger occurred
- File upload(image) : e-mail/FTP
- Notification : e-mail
- Recording : SD/SDHC/SDXC or NAS recording at event triggers
- Alarm output
- Handover(PTZ preset, Send message by HTTP/HTTPS/TCP)
Smart Codec WiseStreamⅢ
Application Programming Interface ONVIF Profile S/G/T/M
Memory 2GB RAM, 1GB Flash
OS / Firmware Protect Secure boot, Signed firmware, Firmware encryption
User authentication Digest Authentication, Prevent brute-force attack
Network authentication 802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2)
Secure Communication HTTPS, SRTP, WSS(Websocket secure)
Access Control Access control based on IP address
Data Protect Authentication information encryption, ZIP compression encryption
Audit User Access/System/Event log management
Device ID Device Certificate(Hanwha Private Root CA)
Secure Storage SDcard partition encrypt
