| Video |
|---|
| Imaging Device | Size | 1/1.8" |
| Type | CMOS |
| Resolution | 320x240, 1280x720, 1280x1024, 720x480, 1280x960, 640x360, 1920x1080, 1600x1200, 640x480, 1024x768, 3072x1728, 2688x1520, 800x600, 3328x1872, 720x576, 800x448, 2592x1944 |
| Max. Framerate | H.265/H.264 | 30fps/25fps(60Hz/50Hz) |
| MJPEG | 30fps(@6MP Max. 5fps) |
| Min. Illumination (Lux) | Color(1/30sec, 30IRE) | 0.04 |
| BW(1/30sec, 30IRE) | 0.004 |
| Video Out | CVBS: 1.0 Vp-p / 75Ω composite for installation, USB: Micro USB Type B |
| Lens |
|---|
| Focal Length (mm) | 4.4~9.3 |
| Zoom Ratio | Optical | 2.1x |
| Max Aperture Ratio (F number) | Wide | 1.3 |
| Tele | 2.15 |
| Angular Field of View | Horizontal | 113°~47° |
| Vertical | 58°~26° |
| Diagonal | 138°~54° |
| Min. Object Distance | 0.5m(1.64ft) |
| Focus Control | Manual, Simple focus |
| Lens Type | P iris(IR corrected) |
| Pan / Tilt / Rotate |
|---|
| Pan / Tilt / Rotate Range | Pan | 0°~360° |
| Tilt | 0°~85° |
| Rotate | 0°~355° |
| Operational |
|---|
| Day & Night | Auto(ICR) |
| Backlight Compensation | HLC, SSDR, BLC, WDR |
| Wide Dynamic Range (dB) | 120 |
| Digital Noise Reduction | WiseNRⅡ(Based on AI engine), SSNRⅤ |
| Digital Image Stabilization | Support(built-in gyro sensor) |
| Defog | Support |
| Motion Detection | Quantity | 8ea |
| Shape | 8point Polygonal zones |
| Privacy Masking | Quantity | 32ea |
| Shape | 4point Quadrangle zones |
| Color / Option | Blue, Gray, Green, Red, White, Black, Mosaic |
| Gain Control | Off, Max gain, Manual |
| White Balance | Indoor, NarrowATW, AWC, ATW, Outdoor, Manual |
| LDC | Support(Fill/stretch mode) |
| Electronic Shutter | Mode | Prefer shutter control(Based on AI engine), Maximum, Anti flicker, Minimum |
| Speed Range | 2~1/12,000sec |
| Video Rotation | Mirror, Flip, Hallway view(90°/270°) |
| Alarm Interface | In/Out | 2 configurable I/O ports |
| Others | 12VDC output |
| Alarm Triggers | Alarm input, App event, Network disconnect, Time schedule, MQTT subscription, Analytics |
| Alarm Events When Alarm Trigger Occurred | Handover: PTZ preset, send message by HTTP/HTTPS/TCP, File upload(video clip): FTP/SFTP, MQTT: publication, Notification: e-mail, Alarm output, Audio clip playback, File upload(image): e-mail/FTP/SFTP, Recording: SD/SDHC/SDXC or NAS recording at event triggers |
| Audio In | Selectable(mic in/line in) |
| Audio Out | Line out |
| Light Type | IR LED |
| Light Viewable Length | IR | WiseIR 50m(164.04ft) |
| IR Wavelength | 850nm |
| Analytics |
|---|
| Classified Object Type | Vehicle, Person, Face, License plate |
| Attributes | Vehicle | Type(car, bus, truck, motorcycle, bicycle) |
| Thumbnail | DetectionShot |
| Analytics Events | Based on AI Engine | Object detection, Motion detection, Virtual area(Loitering/Intrusion/Enter/Exit), Virtual line(Crossing/Direction) |
| Normal | Sound classification, Defocus detection, Shock detection, Virtual area(Appear/Disappear), Fog detection, Tampering, Audio detection |
| Business Intelligence | Based on AI Engine | Heatmap, Queue management, People counting, Vehicle counting |
| Network |
|---|
| Ethernet | Metal shielded RJ-45(10/100/1000BASE-T) |
| Video Compression | H.265/H.264: Main/Baseline/High, MJPEG |
| Audio Compression | G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps, AAC-LC: 48Kbps at 16KHz, G.726(ADPCM) 8KHz, G.711 8KHz, G.711 u-law /G.726 selectable |
| Smart Codec | WiseStreamⅢ, Manual |
| Bitrate Control | H.265/H.264: CBR or VBR, MJPEG: VBR |
| Streaming | Unicast | Up to 20 users |
| Multicast | Support |
| Multiple Streaming | Up to 10 profiles |
| Protocol | RTSP, RTP(UDP), IPv4, HTTPS, FTP, NTP, TCP/IP, ARP, DHCP, RTCP, IPv6, RTP(TCP), SSL/TLS, QoS, SMTP, DDNS, IGMP, HTTP, SFTP, UPnP, CDP, LLDP, MQTT, ICMP, SRTP(TCP, UDP Unicast), UDP/IP, Bonjour, DNS, SNMPv1/v2c/v3(MIB-2) |
| Application Programming Interface | ONVIF | G, M, T, S |
| Others | SUNAPI(HTTP API), Hanwha Vision Open Platform |
| Direct Cloud Connection | Support |
| Security |
|---|
| OS / Firmware Protect | Secure boot, Signed firmware, Encrypted firmware |
| User authentication | Digest authentication, Prevent brute-force attack |
| Network authentication | IEEE 802.1X(EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2) |
| Secure Communication | SRTP, HTTPS, WSS(WebSocket Secure) |
| Access Control | IP-based access control |
| Data Protect | Encryption credentials, Encrypt compress for live recording file export |
| Audit | Access / System / Event Log management |
| Device ID | Device certificate(Hanwha Vision Root CA) |
| Secure Storage | TPM(Trusted platform module), SDcard partition encrypt(AES-256), HTPM(Hanwha Trusted Platform Module) |
| Security Certificate | TPM 2.0 with FIPS 140-2 level2 |
| General |
|---|
| Memory | RAM | 4GB |
| Flash | 512MB |
| Edge Storage | Micro SD/SDHC/SDXC | Max. 512GB x 2slot(Total 1TB) |
| Environmental & Electrical |
|---|
| Operating Condition | Temperature | -50°C~+60°C(-58°F~+140°F) |
| Humidity | 0~100% RH(condensing) |
| Others | Start up should be done at above -30°C, Based on using the camera with housing ※ Supported housing: XNV-6083R, XNV-9082R, XNV-8082R |
| Storage Condition | Temperature | -50°C~+60°C(-58°F~+140°F) |
| Humidity | 0~90% RH(non-condensing) |
| Input Voltage | PoE+(IEEE802.3at, Class4), 12VDC |
| Power Consumption | PoE | Max. 22.5W, typical 17.9W |
| 12VDC | Max. 20W, typical 15.6W |
| Power Redundance Failover | Support |
| Mechanical |
|---|
| Color | Black |
| Material | Aluminum |
| Product Dimensions | ø137.7x104.9mm(5.42x4.13") |
| Product Weight | 750g(1.66lb) |
| Certifications & Standards |
|---|
| Environment | IEC 62262 IK10+, ISO 20653 IP6K9K, IEC 60529 IP66, IEC 60529 IP67 |
| DORI (EN62676-4 standard) |
|---|
| Detect (25PPM/ 8PPF) | Wide | 44.1m(144.54ft) |
| Tele | 153.1m(502.22ft) |
| Observe (63PPM/ 19PPF) | Wide | 17.6m(57.82ft) |
| Tele | 61.2m(200.89ft) |
| Recognize (125PPM/ 38PPF) | Wide | 8.8m(28.91ft) |
| Tele | 30.6m(100.44ft) |
| Identify (250PPM/ 76PPF) | Wide | 4.4m(14.45ft) |
| Tele | 15.3m(50.22ft) |
