Dome

QND-6022R1

2MP IR Dome Camera

Key Features

• Maximum 2megapixel (1920 x 1080) resolution
• 0.03Lux (Color), 0Lux (B/W, IR LED on)
• 4mm fixed lens
• Maximum 30fps@2MP all resolutions (H.265/H.264)
• H.265, H.264, MJPEG codec supported, Multiple streaming
• Motion detection, Tampering, Defocus detection
• Hallway view (90°/270°), LDC support
• Micro SD/SDHC/SDXC memory slot (Max. 128GB)
• IR viewable length 20m, PoE
• No-audio model

Contact Sales Datasheet

["camera","network","dome"]

Product availability may vary by region.
Please contact your regional representative.

Hanwha Vision is formerly known as Hanwha Techwin.

Product Specification

Video
Imaging DeviceSize1/2.8"
TypeCMOS
Resolution1280x720, 720x480, 1280x960, 800x448, 800x600, 720x576, 640x360, 640x480, 1920x1080
Max. FramerateH.265/H.26430fps/25fps(60Hz/50Hz)
MJPEG15fps(@2MP Max. 4fps)
Min. Illumination (Lux)Color(1/30sec, 30IRE)0.03
BW(1/30sec, 30IRE)0.003
Video OutCVBS: 1.0 Vp-p / 75Ω composite for installation
Lens
Focal Length (mm)4.0
Max Aperture Ratio (F number)Wide1.6
Angular Field of ViewHorizontal88°
Vertical47°
Diagonal105°
Min. Object Distance0.5m(1.64ft)
Focus ControlFixed
Pan / Tilt / Rotate
Pan / Tilt / Rotate RangePan0°~350°
Tilt0°~67°
Rotate0°~355°
Operational
Day & NightAuto(ICR)
Backlight CompensationBLC, WDR, SSDR
Wide Dynamic Range (dB)120
Digital Noise ReductionSSNR
Motion DetectionQuantity4ea
Shape8point Polygonal zones
Privacy MaskingQuantity6ea
ShapeRectangular zones
Gain ControlLow, High, Middle
White BalanceATW, Indoor, AWC, Manual, Outdoor
LDCSupport
Electronic ShutterModeMinimum, Maximum, Anti flicker
Speed Range1/5~1/12,000sec
Video RotationFlip, Hallway view(90°/270°), Mirror
Alarm InterfaceIn/OutInput 1ea, Output 1ea
Alarm TriggersNetwork disconnect, Analytics, Alarm input
Alarm Events When Alarm Trigger OccurredAlarm output, File upload(image): e-mail/FTP, Notification: e-mail, Recording: SD/SDHC/SDXC or NAS recording at event triggers, Handover: PTZ preset
Light TypeIR LED
Light Viewable LengthIR20m(65.62ft)
IR Wavelength850nm
Analytics
Analytics EventsNormalTampering, Virtual line(Crossing, Direction) , Virtual area(Intrusion/Enter/Exit), Motion detection, Defocus detection
Network
EthernetRJ-45(10/100BASE-T)
Video CompressionH.265/H.264: Main/High, MJPEG
Smart CodecWiseStreamⅡ
Bitrate ControlH.265/H.264: CBR or VBR, MJPEG: VBR
StreamingUnicastUp to 6 users
MulticastSupport
Multiple StreamingUp to 3 profiles
ProtocolFTP, RTP(UDP), IPv4, HTTPS, NTP, TCP/IP, ARP, DHCP, RTCP, IPv6, UDP/IP, Bonjour, DNS, SNMPv1/v2c/v3(MIB-2), RTP(TCP), SSL/TLS, QoS, SMTP, DDNS, IGMP, HTTP, UPnP, LLDP, RTSP, ICMP
Application Programming InterfaceONVIFS, T, G
OthersHanwha Vision Open Platform, SUNAPI(HTTP API)
Direct Cloud ConnectionOptional (needs gateway)
Security
OS / Firmware ProtectEncrypted firmware
User authenticationDigest authentication, Prevent brute-force attack
Network authenticationIEEE 802.1X(EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2)
Secure CommunicationHTTPS, SRTP, WSS(WebSocket Secure)
Access ControlIP-based access control
Data ProtectEncrypt compress for live recording file export, Encryption credentials
AuditAccess / System / Event Log management
Device IDDevice certificate(Hanwha Vision Root CA)
Secure StorageSDcard partition encrypt(AES-256)
General
MemoryRAM512MB
Flash256MB
Edge StorageMicro SD/SDHC/SDXCMax. 128GB x 1slot
Environmental & Electrical
Operating ConditionTemperature-10°C~+55°C(+14°F~+131°F)
Humidity0~90% RH(non-condensing)
Storage ConditionTemperature-30°C~+60°C(-22°F~+140°F)
Humidity0~90% RH(non-condensing)
Input VoltagePoE(IEEE802.3af, Class3), 12VDC
Power ConsumptionPoEMax. 7.40W, typical 6.00W
12VDCMax. 6.40W, typical 5.10W
Mechanical
ColorWhite
MaterialPlastic
RAL CodeRAL9003
Product Dimensionsø110.0x86.0mm(ø4.33x3.39")
Product Weight255g(0.56lb)
Certifications & Standards
EMCFCC 47 CFR 15 Subpart B Class A, VCCI CISPR 32 Class A, ICES-3(A)/NMB-3(A), RCM AS-NZS CISPR 32 Class A, CE/UKCA - EN55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3, KS C 9832 Class A, KS C 9835
SafetyUL 60950-1, CAN/CSA C22.2 NO. 60950-1, IEC 62471
EnvironmentIEC/EN 63000
DORI (EN62676-4 standard)
Detect (25PPM/ 8PPF)Wide40.0m(131.36ft)
Observe (63PPM/ 19PPF)Wide16.0m(52.54ft)
Recognize (125PPM/ 38PPF)Wide8.0m(26.27ft)
Identify (250PPM/ 76PPF)Wide4.0m(13.14ft)
