QNO-8010R

5M H.265 IR Bullet Camera

Key Features
• Max. 5Megapixel (2592 x 1944) resolution
• 2.8mm fixed lens
• 0.15Lux (Color), 0Lux (B/W, IR LED on)
• H.265, H.264, MJPEG codec support, Multiple streaming
• Day&Night (ICR), WDR (120dB)
• Tampering, Motion detection, Defocus detection
• Micro SD / SDHC / SDXC memory slot (Max. 128GB)
• Hallway view, WiseStream II support
• IR Viewable length 20m (65.62ft)
• IP66, IK10, PoE
Contact Sales Datasheet

["camera","network","bullet"]

Product availability may vary by region.
Please contact your regional representative.

Hanwha Vision is formerly known as Hanwha Techwin.

Overview

High quality cameras offering cost effective solutions
The Q series cameras are affordable products that offer essential features in creating a safe and secure environment.
High quality cameras offering cost effective solutionsHigh quality cameras offering cost effective solutions
5MP and 2MP resolutions
The Q series offers two resolutions options to give you the freedom to choose the camera that best fits your security needs. The 5MP cameras can support up to 30fps, providing real-time video with 2592 x 1944 resolution and up to 15fps of WDR performance, providing crisp and vivid monitoring.
5MP and 2MP resolutions5MP and 2MP resolutions
Enhanced video analytics
The Q series cameras are equipped with a wide range of Intelligent Video Analytics features, helping users detect different types of incidents and have full situational awareness of their facility.
Enhanced video analyticsEnhanced video analytics
Hallway view for monitoring vertical shaped areas
In a vertical shaped environment, such as a store aisle, traditional horizontal shaped cameras waste bandwidth and storage on unnecessary edges. The Hallway view creates 3 : 4 and 9 : 16 ratio video which is vertically oriented and maximizes image quality in a narrow environment.
Hallway view for monitoring vertical shaped areasHallway view for monitoring vertical shaped areas

Product Specification

Video
Imaging Device 1/2.8" CMOS
Resolution 5MP mode : 2592x1944, 1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
4MP mode : 2560x1440, 1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
Max. Framerate H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 15fps(@5MP Max. 2fps)
Min. Illumination Color: 0.15Lux(F2.0, 1/30sec, 30IRE)
BW: 0.015Lux(F2.0, 1/30sec, 30IRE), 0Lux(IR LED on)
Video Out CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation
Lens
Focal Length (Zoom Ratio) 2.8mm fixed focal
Max. Aperture Ratio F2.0
Angular Field of View H: 105°/ V: 77°/ D: 136°
Focus Control Fixed
Pan / Tilt / Rotate
Pan / Tilt / Rotate Range 0°~360° / 0°~100° / 0°~360°
Operational
Camera Title Displayed up to 85 characters
Day & Night Auto(ICR)
Backlight Compensation BLC, WDR, SSDR
Wide Dynamic Range 120dB
Digital Noise Reduction SSNR
Motion Detection 4ea, polygonal zones
Privacy Masking 6ea, rectangular zones
Gain Control Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor
LDC Support
Electronic Shutter Speed Minimum / Maximum / Anti flicker (1/5~1/12,000sec)
Video Rotation Flip, Mirror, Hallway view(90°/270°)
Analytics Motion detection, Tampering, Defocus detection , Virtual area(Intrusion/Enter/Exit), Virtual line(Crossing/Direction)
Alarm I/O Input 1ea / Output 1ea
Alarm Triggers Analytics, Network disconnect, Alarm input
Alarm Events When alarm trigger occurred
- File upload(image): e-mail/FTP
- Notification: e-mail
- Recording: SD/SDHC/SDXC or NAS recording at event triggers
- Alarm output
- Handover: PTZ preset
Light Type IR LED (850nm)
Light Viewable Length 20m(65.62ft)
Network
Ethernet RJ-45(10/100BASE-T)
Video Compression H.265/H.264: Main/High, MJPEG
Smart Codec WiseStreamⅡ
Bitrate Control H.264/H.265: CBR or VBR
MJPEG: VBR
Streaming Unicast(6 users) / Multicast
Multiple streaming(Up to 3 profiles)
Protocol IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP
Application Programming Interface ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform
Security
OS / Firmware Protect Firmware encryption
User authentication Digest Authentication, Prevent brute-force attack
Network authentication 802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2)
Secure Communication HTTPS, SRTP, WSS(Websocket secure)
Access Control Access control based on IP address
Data Protect Authentication information encryption, ZIP compression encryption
Audit User Access/System/Event log management
Device ID Device Certificate(Hanwha Private Root CA)
Secure Storage SDcard partition encrypt
General
Webpage Language English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch
Edge Storage Micro SD/SDHC/SDXC 1slot 128GB
Memory 512MB RAM, 256MB Flash
Environmental & Electrical
Operating Temperature / Humidity -30°C~+55°C(-22°F~+131°F) / 0~90% RH(non-condensing)
* Start up should be done at above -20°C
Storage Temperature / Humidity -30°C~+60°C(-22°F~+140°F) / 0~90% RH
Certification IP66, IK10
Input Voltage PoE(IEEE802.3af, Class3)
Power Consumption PoE: Max 7.50W, typical 6.10W
Mechanical
Color / Material Dark grey / Aluminum
Product Dimensions / Weight ø70.0x246.0mm(ø4.33x3.39"), 680g(1.50 lb)
Backbox SBO-100B1
DORI (EN62676-4 standard)
Detect (25PPM/ 8PPF) 40.0m(131.20ft)
Observe (63PPM/ 19PPF) 16.0m(52.48ft)
Recognize (125PPM/ 38PPF) 8.0m(26.24ft)
Identify (250PPM/ 76PPF) 4.0m(13.12ft)
