Network Cameras
TNO-7180RLP
High-speed License Plate Capture Camera
Key Features
• 3MP, Color Global Shutter Sensor
• 6.8~120mm(18x) motorized varifocal
• H.265, H.264, MJPEG codec
• Maximum 60fps@3MP all resolutions (H.265, H.264, MJPEG)
• Edge Storage Pre-installed with 32GB Micro SD to support 10,000 LPR images
• WiseStreamII support
• HPoE, 12VDC
• IR Viewable Length 50m(164.04ft)
• IP66, IK10, NEMA 4X, NEMA TS 2(2.2.8, 2.2.9)
• Wisenet Road AI application (Pre-installed)
- License/Number Plate Recognition
- Make/Model/Color Recognition
- Black/White list notification
- Smart Search (LP/NP, Country, brand, model, color)
*PoE power supply is not included, must be purchased separately if required
Product availability may vary by region.
Please contact your regional representative.
Hanwha Vision is formerly known as Hanwha Techwin.
Product Specification
| Video | ||
|---|---|---|
| Imaging Device | Size | 1/1.8" |
| Type | CMOS | |
| Resolution | 320x240, 1280x720, 1280x1024, 720x480, 1280x960, 1920x1080, 720x576, 640x360, 640x480, 800x600, 800x448, 2048x1536, 1024x768 | |
| Max. Framerate | H.265/H.264 | 55fps/50fps(55Hz/50Hz)@3MP mode / 60fps/50fps(60Hz/50Hz)@2MP mode |
| MJPEG | 5fps | |
| Min. Illumination (Lux) | Color(1/30sec, 30IRE) | 0.1 |
| BW(1/30sec, 30IRE) | 0.01 | |
| Video Out | USB: Micro USB Type B, CVBS: 1.0 Vp-p / 75Ω composite for installation | |
| Lens | ||
| Focal Length (mm) | 6.8~120 | |
| Zoom Ratio | Optical | 18x |
| Max Aperture Ratio (F number) | Wide | 1.6 |
| Tele | 4.13 | |
| Angular Field of View | Horizontal | 54.5°~3.4° |
| Vertical | 42.3°~2.5° | |
| Min. Object Distance | 2m(6.5ft) | |
| Focus Control | Simple focus, Focus save | |
| Lens Type | DC auto iris | |
| Operational | ||
| Day & Night | Auto(ICR) | |
| Backlight Compensation | SSDR, BLC | |
| Digital Noise Reduction | SSNRⅤ | |
| Motion Detection | Quantity | 8ea |
| Shape | 8point Polygonal zones | |
| Privacy Masking | Quantity | 6ea |
| Shape | Rectangular zones | |
| Color / Option | Gray, Black, White, Blue, Red, Green | |
| Gain Control | Support | |
| White Balance | Outdoor, Indoor, ATW, AWC, Manual | |
| Electronic Shutter | Mode | Minimum, Maximum, Anti flicker, Global shutter mode |
| Speed Range | 1/25~1/12,000sec | |
| Video Rotation | Flip, Mirror | |
| Serial Interface | RS-485(Samsung-T, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell) | |
| Alarm Interface | In/Out | 4 configurable I/O ports |
| Alarm Triggers | Network disconnect, Analytics, Alarm input | |
| Alarm Events When Alarm Trigger Occurred | Notification: e-mail, Recording: SD/SDHC/SDXC or NAS recording at event triggers, File upload(image): e-mail/FTP, Handover: PTZ preset, send message by HTTP/HTTPS/TCP, Alarm output | |
| Audio In | Selectable(mic in/line in) | |
| Audio Out | Line out | |
| Light Type | IR LED | |
| Light Viewable Length | IR | 50m(164ft) |
| IR Wavelength | 850nm | |
| Analytics | ||
| Analytics Events | Normal | Tampering, Motion detection, Virtual area(Lotering, Intrusion, Enter/Exit, Appear/Disappear), Virtual line(Crossing, Direction) |
| Network | ||
| Ethernet | RJ-45(10/100/1000BASE-T) | |
| Video Compression | H.265/H.264: Main/Baseline/High, MJPEG | |
| Smart Codec | WiseStreamⅡ, Manual | |
| Bitrate Control | H.265/H.264: CBR or VBR, MJPEG: VBR | |
| Streaming | Unicast | Up to 20 users |
| Multicast | Support | |
| Multiple Streaming | Up to 10 profiles | |
| Protocol | UPnP, LLDP, RTSP, SRTP(TCP, UDP Unicast), RTP(UDP), PIM-SM, IPv4, HTTPS, FTP, NTP, TCP/IP, ARP, DHCP, RTCP, IPv6, UDP/IP, Bonjour, DNS, SNMPv1/v2c/v3(MIB-2), RTP(TCP), SSL/TLS, QoS, SMTP, DDNS, IGMP, HTTP, ICMP | |
| Application Programming Interface | ONVIF | T, S, G |
| Others | Hanwha Vision Open Platform, SUNAPI(HTTP API) | |
| Security | ||
| OS / Firmware Protect | Secure boot, Encrypted firmware, Signed firmware | |
| User authentication | Prevent brute-force attack, Digest authentication | |
| Network authentication | IEEE 802.1X(EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2) | |
| Secure Communication | WSS(WebSocket Secure), HTTPS | |
| Access Control | IP-based access control | |
| Data Protect | Encrypt compress for live recording file export, Encryption credentials | |
| Audit | Access / System / Event Log management | |
| Device ID | Device certificate(Hanwha Vision Root CA) | |
| Secure Storage | TPM(Trusted platform module) | |
| Security Certificate | TPM 2.0 with FIPS 140-2 level2 | |
| General | ||
| Memory | RAM | 2GB |
| Flash | 256MB | |
| Edge Storage | Micro SD/SDHC/SDXC | 1slot (32GB card preinstalled) |
| Environmental & Electrical | ||
| Operating Condition | Temperature | -40°C~+55°C(-40°F~+131°F) |
| Humidity | 0~95% RH(non-condensing) | |
| Others | Start up should be done at above -40°C | |
| Storage Condition | Temperature | -50°C~+60°C(-58°F~+140°F) |
| Humidity | 0~95% RH(non-condensing) | |
| Input Voltage | PoE++(IEEE802.3bt type3, Class6), 12VDC | |
| Power Consumption | PoE | Max. 50W, typical 27W |
| 12VDC | Max. 47.5W, typical 25W | |
| Mechanical | ||
| Color | White | |
| Material | Aluminum | |
| RAL Code | RAL9003 | |
| Product Dimensions | 186.9(W)x 259.3(H)x293.7(D)mm(7.32x10.2x11.56") | |
| Product Weight | 4,762g(10.5 lb) | |
| Certifications & Standards | ||
| Environment | IEC 60529 IP66, NEMA TS 2-2013 (2.2.8, 2.2.9), NEMA 250 type 4X, IEC 62262 IK10 | |
| Wisenet Road AI LPR/ANPR/MMCR | ||
| Solution | Highways | |
| Speed Description | High Speed | |
| Lane Coverage | Up to 2 lanes | |
| Speed Limit | Up to 200kmh(125mph) for 2 lanes | |
| Min. Forward Distance | 27m(90ft) | |
| Max. Forward Distance | 46m(150ft) | |
| Max. Horizontal Angle | 15° | |
| Max. Vertical Angle | 15° | |
| Horizontal Offset | Up to 4m(12ft) | |
| Camera Height | Up to 7m(24ft) | |
| Vehicle Recognition | Make : 70+ Model : 600+ Color : 11 | |
| Available Countries | Portugal, Moldova, Bulgaria, Russian Federation, Turkmenistan, Belarus, Kyrgyzstan, Czechia, Montenegro, Malta, UAE, Iceland, Tajikistan, Lithuania, Slovenia, Slovakia, Denmark, Cyprus, Mexico, Latvia, Azerbaijan, Belgium, Luxembourg, Finland, North Macedonia, Uzbekistan, Hungary, Ireland, Liechtenstein, Romania, Kazakhstan, Norway, Estonia, United Kingdom, Austria, Albania, Bosnia and Herzegovina, Serbia, San Marino, Spain, Greece, Canada, Georgia, United States of America, Turkey, Ukraine, Switzerland, Germany, Italy, Netherlands, Sweden, Poland, Monaco, Armenia, France | |
